Quick Detail

Main standard:1. Resin sand casting; X, Y, Z rails adopts imported linear guideway; X, Y, Z rails adopt stainless steel telescopic cover; Standard with belt driven spindle; Taiwan production pneumatic cylinder; Taiwan ATC,disc type and chain type are available as option; Imported bearings for leadsrews; Imported coupling; Headstock balancing system have nitrogen balance system or hydraulic balance system as option; NC rotary worktable (B axis); Work lamp; Pilot lamp; USB and LAN interface; Manual pulse generator (MPG); Centralized automatic lubrication system; Cooling system; Heat exchanger for electrical cabinet ; Leveling blocks & bolts;Toolbox and tools;CNC controller: KND,GSK, HNC (China); SIEMENS, FANUC, MITSUBISHI, FAGOR, etc.
Optional: ZF or BF reducer; Circular Coolant Nozzle; Coolant through spindle (CTS); Spindle oil cooler; Air conditioner (A/C) for electrical cabinet; Auto. Tool length measurement system; Auto. Workpiece measurement systems; Optional with sprial type chip conveyor and chain type chip conveyor.

Description

The machine is a high-performance horizontal machining center designed for precision and efficiency. It adopts resin sand casting for excellent structural rigidity and stability. The X, Y, and Z axes are equipped with imported linear guideways, ensuring high positioning accuracy and smooth movement. All axes are protected by stainless steel telescopic covers to prevent chip and coolant ingress. The machine comes standard with a belt-driven spindle, with optional gear-driven solutions via ZF or BF reducers for enhanced torque. The pneumatic cylinder and ATC system are Taiwan-made, with disc-type or chain-type magazines available as options. Imported bearings for ballscrews and imported couplings further ensure transmission accuracy and long service life. The headstock balancing system offers nitrogen or hydraulic balance options. The machine includes a NC rotary worktable (B axis), work lamp, pilot lamp, USB/LAN interfaces, and a manual pulse generator for convenient operation. Centralized automatic lubrication, cooling system, and heat exchanger for the electrical cabinet are standard. Leveling blocks, bolts, and a toolbox are included. The CNC controller can be selected from KND, GSK, HNC (China), or SIEMENS, FANUC, MITSUBISHI, FAGOR, etc. Optional features include circular coolant nozzle, coolant through spindle, spindle oil cooler, electrical cabinet air conditioner, automatic tool and workpiece measurement systems, and spiral or chain chip conveyors.

Applications

The machine is ideal for aerospace, automotive, mold, and general precision machinery manufacturing. It excels in machining complex box-type parts, brackets, and housings requiring multi-face processing. With the B-axis rotary table and high torque options, it handles both heavy roughing and high-speed finishing. It is widely used for engine blocks, gearboxes, pump bodies, and structural components in medium to large batch production.

Specifications

Standard Accessories

※ Resin sand casting
※ X, Y, Z rails adopts imported linear guideway
※ X, Y, Z rails adopt stainless steel telescopic cover
※ Standard with belt driven spindle
※ Taiwan production pneumatic cylinder
※ Taiwan ATC,disc type and chain type are available as option
※ Imported bearings for leadsrews
※ Imported coupling
※ Headstock balancing system have nitrogen balance system or hydraulic balance system as option
※ NC rotary worktable (B axis)
※ Work lamp
※ Pilot lamp
※ USB and LAN interface
※ Manual pulse generator (MPG)
※ Centralized automatic lubrication system
※ Cooling system
※ Heat exchanger for electrical cabinet
※ Leveling blocks & bolts
※ Toolbox and tools
※ CNC controller: KND,GSK, HNC (China); SIEMENS, FANUC, MITSUBISHI, FAGOR, etc.

Optional Accessories

Main standard:1. ZF or BF reducer
※ Circular Coolant Nozzle
※ Coolant through spindle (CTS)
※ Spindle oil cooler
※ Air conditioner (A/C) for electrical cabinet
※ Auto. Tool length measurement system
※ Auto. Workpiece measurement systems
※ Optional with sprial type chip conveyor and chain type chip conveyor

Competitive Advantage

High Rigidity and Stability – Resin sand casting and precision-assembled guideways ensure excellent vibration damping and long-term accuracy.
Flexible Configuration – Multiple controller brands, ATC types, balancing systems, and optional reducers allow customization for various machining needs.
Reliable Core Components – Imported guideways, bearings, couplings, and Taiwan-made pneumatic/ATC systems guarantee consistent performance and low maintenance.
User-Friendly Operation – Standard MPG, USB/LAN interfaces, and centralized lubrication simplify setup and daily use.
Comprehensive Automation Readiness – Optional tool/workpiece measurement, chip conveyors, and CTS support unattended production.
